Chemlock PFA Housings

Overview

Entegris’ Chemlock® PFA housing offers a space-saving solution like no other cartridge filter housing available today. This revolutionary housing locks the cartridge into the bowl, allowing the bowl and cartridge to be removed as a single unit.



Easier Cartridge Changeout

Cartridge changeout has never been easier. The Chemlock bowl is used as a tool when installing and removing a cartridge. After the cartridge is inserted into the bowl, a 1/4-turn locks the cartridge into place. The Chemlock bowl and cartridge filter can be installed into a Chemlock head, quickly and easily. By turning the locking ring, the cartridge ispushed vertically into the housing head, ensuring perfect alignment and double o-ring engagement every time. Operators do not have to touch the cartridge body during cartridge changeout, which minimizes exposure to chemicals and limits the possibility of process contamination.



Specifications:



Materials:

Head, molded-on fittings, bowl and plugs: PFA 440 HP or equivalent
O-ring: Teflon® fluoropolymer encapsulated Viton® fluoroelastomer o-ring (TEV)

Locking ring: PVDF (nonwetted part)

Mounting hardware (nuts and bolts): PVDF (nonwetted parts)

Fluid connections:

Flaretek®, S300 Type Pillar®, Super Type Pillar®, Pipe, FNPT

Cartridge connections:

Code 0, 2-222 O-ring

Operating conditions:

Maximum inlet pressure: 0.3 MPa (3.0 bar, 43 PSI) @ 100°C, 0.75 MPa (7.5 bar, 110 PSI) @ 25°C
Maximum operating temperature: 100°C (212°F)
